Size/Weight
Dimensions
Width ~ 1,350 mm [53-1/8"] Polished finish: 1,353 mm [53-1/4"]
Height ~ 849 mm [33-7/16"] (with music rest raised: 1,003 mm [39-1/2"]) Polished finish: 851 mm [33-1/2"] (with music rest raised: 1,005 mm [39-9/16"])
Depth ~ 411 mm [16-3/16"] Polished finish: 411 mm [16-3/16"]
Weight ~ 45 kg [99 lb, 3 oz] Polished finish: 47 kg [103 lb, 10 oz]
Dimensions of Packing Box W x H x D ~ N/A
Control Interface
Keyboard: Number of Keys ~ 88
Keyboard: Type ~ GrandTouch-S™ keyboard: synthetic ebony and ivory key tops, escapement
Keyboard: Touch Sensitivity ~ Hard, Medium, Soft, Fixed
Keyboard: 88-key Linear Graded Hammers ~ N/A
Keyboard: Counterweight ~ N/A
Pedal
Number of Pedals ~ 3: Damper (with half-pedal function), Sostenuto, Soft
GrandTouch Pedals ~ Yes
Assignable Functions ~ N/A
Display
DisplayType ~ N/A
Display Language ~ N/A
Panel Type ~ N/A
Panel Language ~ English
Cabinet
Cabinet Key Cover Style ~ Sliding
Cabinet Music Rest ~ Yes
Cabinet Music Braces ~ Yes
Voices
Tone Generator: Piano Sound ~ Yamaha CFX, Bösendorfer Imperial
Tone Generator: Binaural Sampling ~ Yes (“CFX Grand” only)
Tone Generator: Virtual Resonance Modeling (VRM) ~ Yes
Tone Generator: Grand Expression Modeling ~ Yes
Polyphony: Number of Polyphony (Max.) ~ 256
Preset: Number of Voices ~ 10
Compatibility ~ N/A
Effects
Type: Reverb ~ 4 types
Type: Chorus ~ N/A
Type: Brilliance ~ N/A
Type: Insertion Effect ~ N/A
Type: Intelligent Acoustic Control (IAC) ~ Yes
Type: Stereophonic Optimizer ~ Yes
Functions: Dual/Layers ~ Yes
Functions: Split ~ N/A
Functions: Duo ~ Yes
Songs
Preset: Number of Preset Songs ~ 10 Voice Demo + 50 Classics + 303 Lesson Songs
MIDI Recording: Number of Songs ~ 1
MIDI Recording: Number of Tracks ~ 2
MIDI Recording: Data Capacity ~ Approx. 250 KB/Song (approx. 11,000 notes)
Audio Recording (USB flash drive): Recording Time (max.) ~ N/A
Compatible Data Format: Playback ~ SMF (Format 0, Format 1)
Compatible Data Format: Recording ~ SMF (Format 0)
Functions
Piano Room ~ N/A
Rhythm: Number of Rhythms ~ N/A
Overall Controls: Metronome ~ Yes
Overall Controls: Tempo Range ~ 5 – 280
Overall Controls: Transpose ~ -6 – 0 – +6
Overall Controls:Tuning ~ 414.8 – 440.0 – 466.8 Hz (approx. 0.2 Hz increments)
Overall Controls: Scale Type ~ N/A
Overall Controls: USB Audio Interface ~ 44.1 kHz, 24 bit, stereo
Bluetooth ~ Audio, MIDI (varies by area)
Storage and Connectivity
Storage: Internal Memory ~ N/A
Storage: External Drives ~ N/A
Connectivity: Headphones ~ Standard stereo phone jack (× 2)
Connectivity:AUX IN ~ N/A
Connectivity: AUX OUT ~ N/A
Connectivity: USB TO DEVICE ~ N/A
Connectivity: USB TO HOST ~ Type B
Connectivity: DC IN ~ 16 V
Amplifiers and Speakers
Amplifiers ~ 20 W × 2
Speakers ~ (12 cm with diffuser) × 2
Power Supply
AC Adaptor ~ PA-300
Power Consumption ~ 12 W (When using PA-300 AC adaptor)
Auto Power Off ~ Yes
Accessories
Included Accessories ~ Owner’s Manual, “50 Classical Music Masterpieces” Music Book, Online Member Product Registration, Bench*, Power cord*/AC adaptor* (PA-500) *Varies by area
Separately Sold Accessories ~ Headphones (HPH-150, HPH-100, HPH-50), Pedal unit (FC35), AC adaptor (PA-500), USB wireless LAN adaptor (UD-WL01)
